CAP VAC INDUSTRIAL 8×4

The CAP VAC INDUSTRIAL is designed for Australia with a simple and ergonomic design built for our working conditions.

With 270 degree boom rotation and an 8″ vacuum hose, this wet / dry vacuum recovery unit is ideal for businesses looking to expand their operational capability to complete more dry excavation work.

The high powered vacuum drives higher producitivty and efficiency for your business whilst reducing operating costs with lower fuel burn than traditional equivalents.

Application

8″ Hydro Excavation

High productivity hydro excavation with dedicated fresh water tank. Optional class ‘A’ high pressure water pump can be fitted.

Dry Vacuum Recovery

Dry vacuum recovery work for applications in the industrial services sector. The capability of the unit to complete dry vacuum recovery applications increases the versatility of the unit and increases the profitability of your business.

Liquid Vacuum Recovery

Wet vacuum recovery allows you to complete high powered vacuum work with traditional wet vacuum recovery applications such as tunnel boring, hydro excavation or liquid vacuum work.

Specs and features

Variant

CAP VAC INDUSTRIAL

Chassis

Scania G450 8×4

Power (Hp)

450hp

Emissions

Euro 5

Wheelbase (Euro)

5,350mm

Turning Circle (Kerb to kerb)

21,864mm

Overall Length

10,320mm

Height

4,100mm

Sludge Tank

8,000 litres, Corten Steel

Water Tank

2,000 litres, Stainless Steel 304

Vacuum Pump

Hibon 840 XL with 6,500 m3/hr (3,800cfm)

Vacuum Efficiency

Max. vacuum 93% (27″Hg)

Dry Vacuum Filtration

Baghouse filter system with automatic cleaning function

Wet Vacuum Filtration

Cyclone – Stainless Steel with automatic cleaning function

Control Panel

Rear mounted Stainless Steel with all functions including unloading

Remote Control

Wireless with all functions including unloading

Hydro Excavation Hose Reel

Stainless Steel spring return 20m x 3/8″ hose

Rear Door Suction Valve

8″ heavy duty inlet with hardened deflector plate

Boom Design

204mm (8″) overhead boom with 270 degree rotational design with 6m extension and articulated end

Sound Levels

Below 85 dB(A) at 1 metre at rear of unit (general working RPM at 1,000RPM)
